POWER PANEL:
POWER ADAPTER(IEC ): Inse rt the includ ed power cable here to charge the unit. Note that the can run off the
power adapter while it simultaneously charges the battery. The charge indicato r illuminates when the battery is
charging.
26.
VOITAGE SELECTOR: Set this to the correct voltage for your location standard.
27.
POWER ON/OFF SWITCH
28.
FUNCTION CHARGING SWITCH:Position USB/SD, the USB/SD function is available,position off,equipment is
powered off,position LINE INPUT,plug in the line level device such as cd player or mixer.
29.
BATTERY LEVEL INDICATOR: While the uni t is power ed ON, these four lights indicat e the power left in the
battery. Battery life varies based on volume and usage.
30.
LINK OUTPUT: This 1/4” jack is a stereo line level output that can be connected to the stereo input of an amplifier
or amplified loudspeaker such as another.
31.
MICROPHONE 1 BALANCED INPUT WITH GAIN CONTROL(1/4” AND XLR):This jack can either take a 1/4”
balanced or a XLR balanced cable. An XLR Cable is included with the microphone.
22.
INSTRUMENT/MICROPHONE 2 INPUT WITH GAIN CONTROL(1/4”): This mono input accepts a 1/4” input such
as a microphone, guitar, or other musical instrument.
23.
MASTER VOLUME CONTROL: This knob controls the master volume of the.
25.
24.
US B / S D / A U X U L I A RY INPUT WITH GAIN CONTROL ( S T E R E O R C A ) : Th i s k n o b c o n trols the
lev e l of t h e USB / SD and t he RCA i n put. Thi s s tere o R CA inp u t can b e use d t o con n ec t a CD,
MP3, or o t h e r au di o so ur c e. To connec t t o a portab l e d ev ic e with a 1/ 8 ” h ea dp h on e ja ck , you
need a standard (1/8” to RCA) adapter which is NOT included.
CONTROL PANEL:
22 23 24 25
POWER S UPPLY
~115/2 30V,60/ 50Hz
POWER C ONSUMPTI ON 70 WATTS
FUSE T2 AL 25 0V
26 28 27 29 3130
