• 7 •
V/Ph/50 Hz
min nom max min nom max
FAMH020SM2M 400 V 3 Ph 7.6 17.7 22.2 6.1 16.1 20.5
FAMH035SM2M 400 V 3 Ph 10.5 27.2 32.4 9.8 22.6 29.0
FASH020SM2M FAIH020SM2M 400 V 3 Ph 7.6 17.7 22.2 6.1 16.1 20.5
FASH035SM2M FAIH035SM2M 400 V 3 Ph 10.5 27.2 32.4 9.8 22.6 29.0
FA M H 020 S M 2 M
V/Ph/50 Hz
min nom max min nom max
FAMH020SM2M 400 V 3 Ph 4.67 2.81 2.67 4.15 3.60 2.23
FAMH035SM2M 400 V 3 Ph 3.27 2.91 2.47 4.71 3.20 2.46
FASH020SM2M FAIH020SM2M 400 V 3 Ph 4.67 2.81 2.67 4.15 3.60 2.23
FASH035SM2M FAIH035SM2M 400 V 3 Ph 3.27 2.91 2.47 4.71 3.20 2.46
Installation Manual • FLATAIR ADV2 IOM-MIL161E-0920-09/2020
1. GENERAL CHARACTERISTICS
1.1. PRODUCT RANGE
UniT
FLATAIR
ADVANCED
H: Heat pump
Type of refrigerant
M: R-410A
Approximate cooling
capacity in kW
M: Package unit
S: Outdoor unit
I: Indoor unit
S: One Circuit
D: Two Circuits
Number of revision
T: 230V/1/50
M: 400V/3/50
1.2. GENERAL DESCRIPTION
The horizontal self-contained conditioners, FLATAIR ADVANCED 2 range, in the heat pump version are air con-
densed units that have been designed for small commercial and residential installations. The units consist of two
sections, an indoor section and an outdoor section, are units that by their design can be supplied in package and split
version. Due to their tight dimensions, they are designed for false ceiling installation, suitable for operation coupled to
a network of air distribution ducts in indoor and outdoor sections. With the option of incorporating a wide range of ac-
cessories and options available and assembled in your factory for your convenience.
The manufacturing of these units is made under the strict quality requirements of the standard ISO 9001.
UNIT HEAT PUMP.
UNITS
Cooling capacity (kW) Heating capacity (kW)
PACKAGED
OUTDOOR UNIT INDOOR UNIT
UNITS
EER
Cooling mode (kW/kW)
COP
Heating mode (kW/kW)
PACKAGED
OUTDOOR UNIT INDOOR UNIT
Cooling: Indoor Tª: 27ºC DB / 19ºC WB. Outdoor Tª: 35ºC DB.
Heating: Indoor Tª: 20ºC DB / 12ºC WB. Outdoor Tª: 7ºC DB / 6ºC WB.
