507581-04Page 50 of 60 Issue 2128
A96UH2E030B08 Performance (Less Filter)
External
Static
Pressure
in. w.g.
Air Volume / Watts at Various Blower Speeds
High Medium-High Medium Medium-Low Low
cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts
0.00 1025 122 935 97 855 76 820 76 765 69
0.10 985 129 910 104 820 82 775 72 700 63
0.20 955 139 875 114 770 87 640 62 575 52
0.30 915 145 830 120 730 96 575 67 375 40
0.40 875 155 790 130 680 101 530 74 330 47
0.50 830 161 750 136 635 110 470 79 260 51
0.60 800 172 700 146 580 115 420 82 210 47
0.70 765 181 650 150 550 124 385 90 180 51
0.80 715 187 615 159 500 127 325 94 135 52
Blower Performance
A96UH2E045B12 Performance (Less Filter)
External
Static
Pressure
in. w.g.
Air Volume / Watts at Various Blower Speeds
High Medium-High Medium Medium-Low Low
cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts
0.00 1345 340 1255 245 1150 185 895 105 845 95
0.10 1305 345 1225 250 1105 200 855 110 810 95
0.20 1290 360 1190 260 1080 205 825 120 780 105
0.30 1275 370 1150 270 1045 215 785 125 720 110
0.40 1220 385 1120 280 1015 220 735 135 690 120
0.50 1215 390 1090 290 980 230 705 140 635 125
0.60 1190 395 1060 300 950 240 650 150 600 135
0.70 N/A N/A 1015 300 900 250 620 155 555 140
0.80 N/A N/A 1000 310 870 260 580 160 520 145
