MULTIDIRECTIONAL HORIZONTAL ROOFCURB
BALTIC R410A-IOM-0708-E Page 45
BAC
BAH
BAG
BAM
065 075
1F 2F
1F’
Front supply air
2F’
Front return air
WARNING : ONLY ONE OF THE 4 FOLLOWINGS POSSIBILITIES :
2F - 1F / 2F - 1F'
2F' - 1F / 2F' - 1F'
