Page 18 - IOM / ROOFTOP BALTIC Series - 0704 - E
adjustable ROOFCURB DRAWINGS
030 035
A-A
103.5 1282 103.5
1383 1743
401
103.51642103.5
747 318
158347
90.5
847.5
97.5
227.5100
A
BCD
A
A
D
8
5D
2D
2D
4D
2D
DownReturn Air
1D
Down Supply Air
Down main power entry
5D
Down hot water
Entry
8
Main Power Entry
Roof opening 1642 x 1282
ABCD
BCK / BHK without auxiliary heating 496 633 400 349
BGK / BDK or BCK / BHK with auxiliary heating 636 351 790 241
