IOM / ROOFTOP BALTIC Series - 0704-E Page 21
adjustable ROOFCURB DRAWINGS
4D
2D
DownReturn Air
1D
Down Supply Air
Down main power entry
5D
Down hot water
Entry
8
Main Power Entry
060 070
BGK
BDK
(*) This roofcurb is also necessary for all cooling
only or heatpump rooftop with auxiliary electric
heater or hot water coil.
2082
2092
401
103.51992103.5103.51982103.5
347 199
292.51497292.5
380287380 431.5
410466
97
1197
D
D
8
5D
2D
2D
