MULTIDIRECTIONAL HORIZONTAL ROOFCURB
035030
BCK
BHK
1F'
Front supply air
2F
2F'
Front return air
1F
Front supply air
WARNING : ONLY ONE OF THE 4 FOLLOWINGS POSSIBILITIES :
2F - 1F / 2F - 1F'
2F' - 1F / 2F' - 1F'
Front return air
(*) without auxiliary electric heater
without hot water coil.
