Page 26 - IOM / ROOFTOP BALTIC Series - 0704 - E
2F'
2F
1F
2F'
1F
1F'
2F
2F'
1F
1F'
2F
2F'1F
1F'
MULTIDIRECTIONAL HORIZONTAL ROOFCURB
045 050040
BGK
BDK
1F'
Front supply air
2F
2F'
Front return air
1F
Front supply air
WARNING : ONLY ONE OF THE 4 FOLLOWINGS POSSIBILITIES :
2F - 1F / 2F - 1F'
2F' - 1F / 2F' - 1F'
Front return air
(*) This roofcurb is also necessary for all cooling only or heatpump
rooftop with auxiliary electric heater or hot water coil.
