Page 98 - IOM / ROOFTOP BALTIC Series - 0704 - E
Main Screen Code Description Code Description Code Description Code UNIT Min Factory Max Description
3-Fan 2300 1-Ventilation 2310 Config. 2311 List [No / 500pa / 100pa]
State 2312 List [Stopped / Schedule / Fault / Start]
Sw State 2313 On/Off
Fire/Smoke 2314 On/Off
Relay 2315 On/Off
Low Speed 2316 On/Off
Sw Speed 2317 On/Off
2-Extraction 2320 State 2321 List [Stopped / Schedule / Fault / Start]
Relay 2322 On/Off
3-Condenser 1 2330 Config. 2331 List [No / Yes]
State 2332 List [Stopped / Schedule / Fault / Start]
Sw State 2333 On/Off
Relay 2334 On/Off
4-Condenser 2 2340 Config. 2341 List [No / Yes]
State 2342 List [Stopped / Schedule / Fault / Start]
Sw State 2343 On/Off
Relay 2344 On/Off
5-Condenser 3 2350 Config. 2351 List [No / Yes]
State 2352 List [Stopped / Schedule / Fault / Start]
Sw State 2353 On/Off
Relay 2354 On/Off
6-Condenser 4 2360 Config. 2361 List [No / Yes]
State 2362 List [Stopped / Schedule / Fault / Start]
Sw State 2363 On/Off
Relay 2364 On/Off
4-Cooler 2400 1-Fresh Air 2410 Config. 2411 List [No / 0%-50% / Modulation / 100%]
State 2412 List [Stopped / Air Flow / Start / Enthalpy /
Outside T. / Schedule / Defrost]
Mini.Air 2413 %
Modulat. 2414 %
Opening 2415 %
Calib. 2416 Yes/No
control interfaces ds50 menu tree
