Lennox Baltic BHK 070 - Adjustable Roof Curb

IOM / ROOFTOP BALTIC Series - 0704-E Page 17
4D
2D
DownReturn Air
1D
Down Supply Air
Down main power entry
5D
Down hot water
Entry
8
Main Power Entry
A-A
1186
103.5 1085 103.5 103.5 1795 103.5
1896
319.2 547 319.5
15834747690.5
848
247.5
12890
A
B
AA
D
D
8
5D
2D
2D
adjustable ROOFCURB DRAWINGS
Roof opening 1795 x 1085
AB
BCK / BHK without auxiliary heating 543 395
BGK / BDK or BCK / BHK with auxiliary heating 247 691
020 025
