Page 6
CBA27UHE PARTS ARRANGEMENT
FIGURE 1
CONTROL BOX
ELECTRIC HEAT
SECTION
BLOWER
COMPARTMENT
COIL
HORIZONTAL
DRAIN PAN
EXPANSION VALVE
(COMPLETE WITH
SCREEN)
*BLOWER ACCESS
PANEL
*COIL ACCESS
PANEL
FILTER ACCESS
PANEL
FILTER
