Lennox Comfort Series User Manual

Part identification
Vertical airflow direction vane
(Airflow direction adjustment up and down).
Air direction adjustment
Front grille
Air inlet louver
Cabinet
Air filter
Front intake grille
Remote control panel
Panel outlook picture, just for reference, please take the real until as standard.
(behind the front intake grille)
Power cord
The vertical airflow direction vane is controlled by positioning the vane
to discharge the air upwards, downwards or straight out.
- 6 -
