• 70 • Installation - Operation - Maintenance manual • CHILLERS • ANNEXES - 0105-E
OPERATION -
CLIMATIC™ 50 - Menu Tree - ECOLOGIC rangeCLIMATIC™ 50 - Menu Tree - ECOLOGIC range
CLIMATIC™ 50 - Menu Tree - ECOLOGIC rangeCLIMATIC™ 50 - Menu Tree - ECOLOGIC range
CLIMATIC™ 50 - Menu Tree - ECOLOGIC range
Main screen Code Description Code Description Code Description Code Unit Min Factory Max
1-Alarm 1000 1-(date).(time)
2-(date).(time)
3-(date).(time)
2-Data 2000 1-General 2100 1-Temperature 2110 1-Outside 2111 °C
2-Inlet 2112 °C
3-Outlet 2113 °C
2-Circuit 1 2120 1-SuperHeat 2121 °C
2-T°. Condensing 2122 °C
3-T°- Saturated 2123 °C
4-T°. Suction 2124 °C
5-P. Condensing 2125 b
6-P. Saturated 2126 b
3-Circuit 2 2130 1-SuperHeat 2131 °C
2-T°. Condensing 2132 °C
3-T°- Saturated 2133 °C
4-T°. Suction 2134 °C
5-P. Condensing 2135 b
6-P. Saturated 2136 b
4-Other 2140 1-Sw On/Off 2141 On/Off
2-Sw Flow 2142 On/Off
3-Sw Dis. C1 2143 On/Off
4-Sw Dis. C2 2144 On/Off
5-Sw Reset 2145 On/Off
6-Sw Unoc. 2146 On/Off
5-Out. Custom. 2150 1-Relay 1 2151 On/Off
2-Relay 2 2152 On/Off
3-Relay 3 2153 On/Off
4-Relay 4 2154 On/Off
6-In. Custom. 2160 1-Switch 1 2161 On/Off
2-Switch 2 2162 On/Off
3-Switch 3 2163 On/Off
4-Switch 4 2164 On/Off
