Main screen Code Description Code Description Code Description Code Unit Min Factory Max
7-In. % Custom 2170 1-Temp. 1 2171 °C
2-Temp. 2 2172 °C
3-Temp. 3 2173 °C
4-Temp. 4 2174 °C
2-Control 2200 1-Water 2210 1-Sp Cool 2211 °C
2-Sp Heat 2212 °C
3-Cap.Cool 2213 %
4-Cap.Heat 2214 %
5-Sw 2°Sp 2215 On/Off
6-Offset 2216 °C
2-Ventilation 2220 1-SetPoint 2221 b
2-Capa. V1 2222 %
3-Capa. V2 2223 %
3-Pump 1-Config. 2311 Liste
2-State 2312 Liste
3-Sw Flow 2313 On/Off
4-Sw State 2314 On/Off
5-Relay 1 2315 On/Off
6-Running T. 1 2316 h
7-Relay 2 2317 On/Off
8-Running T. 2 2318 h
4-Compressor 2400 1-Comp.1 - Circ.1 2410 1-Config. 2411 Liste
2-State 2412 Liste
3-Sw State 2413 On/Off
4-Sw High P. 2414 On/Off
5-Sw Low P. 2415 On/Off
6-Relay 2416 On/Off
7-H.Pump 2417 On/Off
8-Bypass 2418 On/Off
9-Run Time 2419 h
OPERATION -
CLIMATIC™ 50 - Menu Tree - ECOLOGIC rangeCLIMATIC™ 50 - Menu Tree - ECOLOGIC range CLIMATIC™ 50 - Menu Tree - ECOLOGIC rangeCLIMATIC™ 50 - Menu Tree - ECOLOGIC range
CLIMATIC™ 50 - Menu Tree - ECOLOGIC range
CLIMATIC™ 50 - Menu Tree - ECOLOGIC range (continued)
