• 76 • Installation - Operation - Maintenance manual • CHILLERS • ANNEXES - 0105-E
Main
screen
Code Description Code Description Code Description Code Unit Min Factory Max Comments
3-Sp Out.1 3323 °C
-10 22 50
*[Water SP] Ambiant air temperature set point (see
page 13 – IOM Climatic 50)
4-Sp Out.2 3324 °C
-10 30 50
*[Water SP] Ambiant air temperature set point (see
page 13 – IOM Climatic 50)
5-Reactiv. 3325 %/°C
1 5 50
*[Capacity Factor] Reactivity factor for cooling mode
3-Water
Heat
3330 1-Sp Wat.1 3331 °C
17 40 50
*[Water SP] Outlet hot water temperature set point
(see page 13 – IOM Climatic 50)
2-Sp Wat.2 3332 °C
17 40 50
*[Water SP] Outlet hot water temperature set point
(see page 13 – IOM Climatic 50)
3-Sp Out.1 3333 °C
-10 19 50
*[Water SP] Ambiant air temperature set point (see
page 13 – IOM Climatic 50)
4-Sp Out.2 3334 °C
-10 0 50
*[Water SP] Ambiant air temperature set point (see
page 13 – IOM Climatic 50)
5-Reactiv. 3335 %/°C
1 5 50
*[Capacity Factor] Reactivity factor for heating mode
4-Safety 3340 1-Wat. Low 3341 °C
3 / -10 5 / -10 12
*[Safety limit] Chilled water outlet temperature limit –
minimum with Glycol according to %
2-Wat. High 3342 °C
22 53 53
*[Safety limit] Hot water outlet temperature limit
4-
Compressor
3400
1-Circuit 3410 1-Rotat. 3411 Liste
0 4 4
*[Comp priority] Circuit priority management
2-Safety 3420 1-Frost 3421 °C
-1/-20 -1 / -20 5
*[Safety limit] Freezing safety limit – minimum with
Glycol according to %
3-Defrost 3430 1-Mode 3431 Liste
0 0 1
*[ Function Defrost ] Choice of defrost: 1 =
"cycling" or 0 ="dynamic"
2-Outside 3432 °C
8 10 20
*[ Function Defrost ] Authorization of defrost -
Threshold of outside temperature (in °c)
3-Coil 3433 °C
-10 2 10
*[ Function Defrost ] Authorization of defrost -
Threshold of coil temperature (in °c)
4-Time Limit 3434 m
30 45 90
*[ Function Defrost ] Time limit for icing (in
minute) -For the dynamic defrost the unit will run
this minimum amount of time. If cycling defrost
this is the time delay to start the defrost once the
temperature conditions are met.
5-Time Fc 3435 s
5 60 300
*[ Function Defrost ] Running time of fans after
defrost cycle in order to dry the outside coil.
5-EEV 3500
1-Cooling 3510 1-SuperHeat 3511 °C
2 5 15
*[ EEV] Superheat set point
2-Dead zone 3512 °C
0 0 9,9
*[ EEV] Lennox set point
3-P 3513 °C
0 3,5 99,9
*[ EEV] Lennox set point – Proportional factor
4-I 3514 s
0 30 999
*[ EEV] Lennox set point – Integral factor
5-D 3515 s
0 1 999
*[ EEV] Lennox set point – Derivate factor
6-
Ventilation 3600
1-Sp Cond. 3611 b
12 17 / 11 30
*[ HP SP] High pressure set point – for R134a unit
2-Reactiv. 3612 %/°C
1 5 50
*[ HP Factor] Reactivity set point for fan operation
7-Option 3700
OPERATION -
CLIMATIC™ 50 - Menu Tree - ECOLOGIC rangeCLIMATIC™ 50 - Menu Tree - ECOLOGIC range
CLIMATIC™ 50 - Menu Tree - ECOLOGIC rangeCLIMATIC™ 50 - Menu Tree - ECOLOGIC range
CLIMATIC™ 50 - Menu Tree - ECOLOGIC range
CLIMATIC™ 50 - Menu Tree - ECOLOGIC range (continued)
