Installation - Operation - Maintenance manual • CHILLERS • ANNEXES - 0105-E • 77 •

Main

screen

Code Description Code Description Code Description Code Unit Min Factory Max Comments

8-Config. 3800

1-Unit 3810 1-Range 3811 Liste

0 ~ 8

*[ Configuration ] Unit model

2-Size 3812 Liste

0 ~ 61

*[ Configuration ] Type of unit

3-Pump 3813 Liste

0 ~ 2

*[ Configuration ] Pump configuration

4- gaz 3814 Liste

0 ~ 1

*[ Configuration ] Type of refrigerant R407C –

R134a –R22

5-EEV 3815 Yes/No

~ ~ ~

*[ Configuration ] Electronic expansion valve

6-Modul. Fan 3816 Yes/No

~ ~ ~

*[ Configuration ] Fan control type

7-LAK 3817 Yes/No

~ ~ ~

*[ Configuration ] All season control

8-Glycol 3818 %

0 ~ 50

*[ Configuration ] Glycol persentage

9-Recovery 3819 Yes/No

~ ~ ~

*[ Configuration ] Heat recovery option

2-Out.

Custom.

3820 1-BE50.1 3821 Liste

0 0 6

*[Configuration] Free output to be customised

(First output of the extension board BE50)

2-BE50.2 3822 Liste

0 0 6

*[Configuration] Free output to be customised

(Second output of the extension board BE50)

3-BE50.3 3823 Liste

0 0 6

*[Configuration] Free output to be customised

(Third output of the extension board BE50)

4-BE50.4 3824 Liste

0 0 6

*[Configuration] Free output to be customised

(Fourth output of the extension board BE50)

3-In.

Custom.

3830 1-BE50.1 3831 Liste

0 0 5

*[Configuration] Free input to be customised
