Code Description Code Description Code Description Code Unit Min Factory Max Comments
9-Com. 3900
1-Display 3910 1-Standard Sp 3911 Yes/No
~ Off ~
*Allows a reset of ALL set point to standard
factory settings (when available).No possible
for configurations. and clock as there is no
factory settings for these.
2-Link 3920 1-ID 3921 ~
1 ~ 4
*[ Configuration ] Identification adress for the
unit from 1 to 4 for master slave operation.
1-Number 3922 ~
1 1 4
*[ Configuration ] Number of units on the BUS.
Unit with address N°1 is always the master.
2-Type 3923 Liste
0 0 2
*Master / Slave relationship: refer to page 7 for
details
3-BMS 3930 1-ID 3931 ~
1 1 200
*[ Configuration ] Identification number on the 485
Bus
2-Type 3932 Liste
0 0 2
*[ Configuration ] Type of BMS 0 Mode Lennox
Climatic; 1 MODBUS; 2 LONWORKS
3-Baud 3933 Liste
0 3 4
BMS communication speed between 1200BDS
and 19800
4-Watchdog 3934 ~
0 0 1000
*[ BMS ] Activation of the control by a computer
or an automat
- mode BMS is activated if this value is
different from zero, This value is decreased
every second
5-BMS Unoc. 3935 On/Off
~ Off ~
*[BMS] Cancel the override unnocupied mode
OPERATION -
CLIMATIC™ 50 - Menu Tree - ECOLOGIC rangeCLIMATIC™ 50 - Menu Tree - ECOLOGIC range
