OPERATION -
CLIMATIC™ 50 - Menu Tree - ECOMAX rangeCLIMATIC™ 50 - Menu Tree - ECOMAX range
CLIMATIC™ 50 - Menu Tree - ECOMAX rangeCLIMATIC™ 50 - Menu Tree - ECOMAX range
CLIMATIC™ 50 - Menu Tree - ECOMAX range
Main screen Code Description Code Description Code Description Code Unit Min Factory Max
1-Alarm 1000 1-(date).(time)
2-(date).(time)
3-(date).(time)
2-Data 2000 1-General 2100 1-Temperature 2110 1-Outside 2111 °C
2-Inlet 2112 °C
3-Outlet 2113 °C
2-Circuit 1 2120 1-SuperHeat 2121 °C
2-T°. Condensing 2122 °C
3-T°- Saturated 2123 °C
4-T°. Suction 2124 °C
5-P. Condensing 2125 b
6-P. Saturated 2126 b
3-Circuit 2 2130 1-SuperHeat 2131 °C
2- T°.Condensing 2132 °C
3- T°- Saturated. 2133 °C
4- T°. Suction. 2134 °C
5- P. Condensing 2135 b
6- P. Saturated 2136 b
4-Circuit 3 2140 1-SuperHeat 2141 °C
2-T°. Condensing 2142 °C
3-T°- Saturated 2143 °C
4-T°. Suction 2144 °C
5-P. Condensing 2145 b
6-P. Saturated 2146 b
5-Circuit 4 2150 1-SuperHeat 2151 °C
2- T°.Condensing 2152 °C
3- T°- Saturated. 2153 °C
4- T°. Suction. 2154 °C
5- P. Condensing 2155 b
6- P. Saturated 2156 b
