Lennox ECOLOGIC Series - Page 90

• 88 • Installation - Operation - Maintenance manual • CHILLERS • ANNEXES - 0105-E
Main
screen
Code Description Code Description Code Description Code Unit Min Factory Max Comments
3-
Ventilation
3830 1-Circuit 1 3831 Liste
0 0 2
*[ Configuration ] Fan configuration
No = No fans
Stages + = Single speed stage fans
Modulation = 1 fan with speed control, others with
single speed
Low Speed = 1 fan with 2 speed others with single
speed
2-Circuit 2 3832 Liste
0 0 2
*[ Configuration ] Fan configuration
No = No fans
Stages + = Single speed stage fans
Modulation = 1 fan with speed control, others with
single speed
Low Speed = 1 fan with 2 speed others with single
speed
3-Circuit 3 3833 Liste
0 0 2
*[ Configuration ] Fan configuration
No = No fans
Stages + = Single speed stage fans
Modulation = 1 fan with speed control, others with
single speed
Low Speed = 1 fan with 2 speed others with single
speed
4-Circuit 4 3834 Liste
0 0 2
*[ Configuration ] Fan configuration
No = No fans
Stages + = Single speed stage fans
Modulation = 1 fan with speed control, others with
single speed
Low Speed = 1 fan with 2 speed others with single
speed
OPERATION -
CLIMATIC™ 50 - Menu Tree - ECOMAX rangeCLIMATIC™ 50 - Menu Tree - ECOMAX range CLIMATIC™ 50 - Menu Tree - ECOMAX rangeCLIMATIC™ 50 - Menu Tree - ECOMAX range
CLIMATIC™ 50 - Menu Tree - ECOMAX range
CLIMATIC™ 50 - Menu Tree - ECOMAX range (continued)
