CLIMATIC™ 50 - Menu Tree - ECOMAX rangeCLIMATIC™ 50 - Menu Tree - ECOMAX range CLIMATIC™ 50 - Menu Tree - ECOMAX rangeCLIMATIC™ 50 - Menu Tree - ECOMAX range
CLIMATIC™ 50 - Menu Tree - ECOMAX range
Main
screen
Code Description Code Description Code Description Code Unit Min Factory Max Comments
4-Option. 3840 1-Pump 3841 Liste
0 ~ 2
*[ Configuration ] Pump configuration
2-Glycol 3842 %
0 ~ 50
*[ Configuration ] Glycol persentage
3-Recovery 3843 Yes/No
~ ~ ~
*[ Configuration ] Heat recovery option
5-Out.
Custom.
3850 1-BE50.1 3851 Liste
0 0 6
*[Configuration] Free output to be customised
(First output of the extension board BE50)
2-BE50.2 3852 Liste
0 0 6
*[Configuration] Free output to be customised
(Second output of the extension board BE50)
3-BE50.3 3853 Liste
0 0 6
*[Configuration] Free output to be customised
(Third output of the extension board BE50)
4-BE50.4 3854 Liste
0 0 6
*[Configuration] Free output to be customised
(Fourth output of the extension board BE50)
6-In.
Custom.
3860 1-BE50.1 3861 Liste
0 0 5
*[Configuration] Free input to be customised
(input of the extension board BE50)
2-BE50.2 3862 Liste
0 0 5
*[Configuration] Free input to be customised
(input of the extension board BE50)
3-BE50.3 3863 Liste
0 0 5
*[Configuration] Free input to be customised
(input of the extension board BE50)
4-BE50.4 3864 Liste
0 0 5
*[Configuration] Free input to be customised
(input of the extension board BE50)
7-In.%
Custom.
3870 1-BE50.1 3871 Liste
0 0 2
*[Configuration] Free input to be customised
(input of the extension board BE50)
2-BE50.2 3872 Liste
0 0 2
*[Configuration] Free input to be customised
(input of the extension board BE50)
3-BE50.3 3873 Liste
0 0 2
*[Configuration] Free input to be customised
(input of the extension board BE50)
4-BE50.4 3874 Liste
0 0 2
*[Configuration] Free input to be customised
(input of the extension board BE50)
CLIMATIC™ 50 - Menu Tree - ECOMAX range (continued)
