Deluxe Remote Control System
The Model RC-STAT (Deluxe) Remote Control
System has all of the features of the standard
system along with an added easy to read LCD
screen which presents access to many en-
hancements, including; battery power level in-
dicator, timer, mode of operation, thermostatic
display including room temperature in either
metric of English units, flame indicator and
clock. Fully programmable, the Model RC-
STAT allows for virtual command over nearly all
operational and temperature variables, using
the hand held remote control transmitter.
The Model RC-STAT (Deluxe) remote control
system is installed in the same manner as the
standard system, may be operated with elec-
tronic and millivolt systems with either natural
or propane gas. The RC-STAT comes complete
with detailed operating instructions.
Remote Control System (Deluxe) 98K99 RC-STAT
Screen Panel Kit 96K33 HG45
Screen Panel Kit
An optional screen panel can be installed on the
4540 Series door. This screen panel is easy to
install. This kit can be retrofitted to previously
installed appliances. The screen panel kit can not
be used in conjunction with either of the arch
door kits or door frame kits.
Arch Door Kits
Brass Finish 81L36 ADK45CPB
Brushed Stainless Finish 98L70 ADK45CBS
Arch Door Kits
Two arch door kits are available for the 4540
Series. Both kits are easy to install and do not
require hardware to attach them to the standard
door frame. These kits can be retrofitted to
previously installed 4540 Series appliances.
The decorative arch kits can not be used in
conjunction with the screen panel kit.
Clean Faced Panel Kits
Painted 88L38 RAD45C-2
Brass Finish 88L42 RAD45PB-2
Clean Faced Panel Kit
A clean faced panel kit is available to convert the
standard louvered appliances to radiant models
more suited for finishing around the firebox
opening with non-combustible materials such
as tile.
Remote Control System (Standard) 26N04 RC
ACCESSORY COMPONENTS
Standard Remote Control System
The Model RC (Standard) Remote Control
System, features a simplistic on/off control
function for the fireplace. This model includes
a hand-held transmitter, a remote receiver
with wall-mount coverplate and all hardware
required to install the unit. The remote re-
ceiver can be wall or hearth mounted.
The transmitter has ON and OFF functions that
are activated by pressing either button on the face
of the transmitter. When a button on the trans-
mitter is pressed, a signal light illuminates briefly
to verify that a signal has been sent.
The Model RC is designed to operate with all
millivolt ignition systems, as well as electronic
ignition systems. It may be installed with use for
either natural or propane gas appliances. The RC
offers ease of installation and allows you to
execute on-off commands to the fireplace effort-
lessly with one simple motion.
The Model RC comes complete with detailed
operating instructions.
SIGNAL
LIGHT
ON/OFF
BUTTONS
ON
INDICATOR
OFF
SET
COVER
OPEN
LCD SCREEN
MODE
UP
DOWNTIMER/
TIME
To Next Page
