PARTS IDENTIFICATION
TOP CAP
BURNER BOX
ASSEMBLY
DuralokPlus
TM
HEAT EXCHANGER
ASSEMBLY
CONTROL BOX
former, circuit breaker and interlock
switch)
COMBUSTION AIR
INDUCER
OUTER
ACCESS
PANEL
COMBUSTION
AIR PRESSURE
SWITCH
PRIMARY LIMIT
GAS VALVE
BLOWER
ASSEMBLY
FLEXIBLE NO-HUB
EXHAUST COLLAR
COLD END
HEADER BOX
BAG ASSEMBLIES
(shipping location)
BLOWER ACCESS
PANEL
FIGURE 1
