Lennox EL296DFV - Unit Dimensions - Inches (MM)

Page 2
Unit Dimensions - inches (mm)
AIR
EXHAUST AIR
OUTLET
COMBUSTION
AIR INTAKE
FLOW
2-1/16 (52)
GAS PIPING INLET
(Either Side)
RETURN AIR
OPENING
FRONT VIEW SIDE VIEW
TOP VIEW
A
B
C
3/4
(19)
27-3/4
(705)
19-1/4
(489)
9-1/8 (232) Right
6-9/16 (167) Left
2 (51)
Either Side
33
(838)
3/4
(19)
B
Supply
Air
Supply
Air
9/16
(14)
9/16
(14)
9/16
(14)
9/16
(14)
19-7/16
(494)
3/4
(19)
CONDENSATE
TRAP CONNECTION
5
(127)
6-7/16 (163)
Either Side
9 (229)
Either Side
2-1/4
(57)
(Either Side)
1-1/2 (38)
Front Panel
1-7/8 (48)
1 (25)
6-1/4
(157)
15
(381)
4-1/2
(114)
2-1/16
(52)
5-3/16
(132)
OPTIONAL LEFT SIDE
VENT LOCATION
(Kit Required)
ALTERNATE RIGHT SIDE
VENT LOCATION
(Parts Furnished)
ELECTRICAL INLET
(Either Side)
ELECTRICAL INLET
(Either Side)
Flue Condensate Trap Assembly
Furnished for external
field installation
on either side of unit.
(See installation instructions
for additional
information.)
7
(178)
Model No.
A
in. (mm)
B
in. (mm)
C
in. (mm)
EL296DFXV045P36B
EL296DFXV070P48B
17-1/2 (446) 16-3/8 (416) 16 (406)
EL296DFXV090P60C
EL296DFXV110P60C
21 (533) 19-7/8 (505) 19-1/2 (495)
