BLOWER/WATTS DATA
G32Q3−75 BLOWER PERFORMANCE
External Static
Air Volume and Motor Watts at Specific Blower Taps
Pressure
High Medium−High Medium−Low Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts
0 0 1490 705 650 1340 630 540 1060 500 440 870 410 360
.10 25 1435 675 625 1305 615 515 1050 495 425 865 410 350
.20 50 1385 655 605 1260 595 490 1025 485 405 850 400 335
.30 75 1330 630 580 1215 575 470 1000 470 385 835 395 325
.40 100 1260 595 560 1160 545 445 965 455 365 810 380 310
.50 125 1200 565 540 1100 520 420 920 435 345 770 365 290
.60 150 1125 530 515 1035 490 400 870 410 325 735 345 280
.70 175 1035 490 495 960 455 375 780 370 305 685 325 265
.80 200 935 440 475 865 410 345 725 340 285 − − − − − − − − − − − −
.90 225 805 380 445 630 295 295 540 255 240 − − − − − − − − − − − −
NOTE All air data is measured external to unit with 1 in. (25 mm) cleanable foam filter (not furnished) in place. Also see Filter Air Resistance table.
G32Q3/4−100 BLOWER PERFORMANCE
External Static
Air Volume and Motor Watts at Specific Blower Taps
Pressure
High Medium−High Medium−Low Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts
0 0 2065 975 920 1760 830 735 1570 740 655 1245 590 520
.10 25 2000 945 875 1730 815 705 1550 730 625 1240 585 490
.20 50 1925 910 845 1685 795 675 1515 715 590 1225 580 470
.30 75 1840 870 800 1625 765 630 1475 695 565 1210 570 455
.40 100 1740 820 760 1550 730 595 1415 670 535 1165 550 430
.50 125 1650 780 730 1460 690 560 1335 630 500 1110 525 405
.60 150 1545 730 700 1370 645 530 1260 595 475 1045 495 385
.70 175 1420 670 660 1250 590 495 1170 550 445 950 450 355
.80 200 1270 600 620 1110 525 445 1025 485 395 825 390 325
.90 225 1045 495 560 965 455 405 885 420 360 700 330 290
NOTE All air data is measured external to unit with 1 in. (25 mm) cleanable foam filter (not furnished) in place. Also see Filter Air Resistance table.
G32Q4/5−100 BLOWER PERFORMANCE
External Static
Air Volume and Motor Watts at Specific Blower Taps
Pressure
High Medium−High Medium Medium−Low Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts
0 0 2400 1135 1255 2185 1030 1070 1940 915 905 1740 820 765 1570 740 665
.10 25 2350 1110 1230 2150 1015 1055 1920 905 885 1710 805 755 1525 720 645
.20 50 2290 1080 1185 2105 995 1025 1875 885 865 1685 795 740 1505 710 640
.30 75 2225 1050 1170 2060 970 1005 1845 870 850 1655 780 730 1485 700 630
.40 100 2165 1020 1130 2010 950 985 1805 850 835 1620 765 720 1450 685 620
.50 125 2105 995 1115 1950 920 960 1755 830 810 1585 750 700 1415 670 605
.60 150 2040 965 1080 1895 895 940 1700 800 790 1540 725 690 1380 650 595
.70 175 1955 925 1045 1820 860 915 1640 775 775 1475 695 670 1340 630 590
.80 200 1850 875 1005 1730 815 885 1580 745 755 1430 675 660 1290 610 580
.90 225 1770 835 985 1650 780 855 1505 710 740 1370 645 645 1225 580 565
NOTE All air data is measured external to unit with 1 in. (25 mm) cleanable foam filter (not furnished) in place. Also see Filter Air Resistance table.
G32Q4/5−125 BLOWER PERFORMANCE
External Static
Air Volume and Motor Watts at Specific Blower Taps
Pressure
High Medium−High Medium Medium−Low Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts
0 0 2400 1135 1210 2175 1025 1040 1965 925 895 1790 845 780 1610 760 670
.10 25 2315 1090 1175 2125 1005 1025 1930 910 875 1760 830 770 1580 745 660
.20 50 2255 1065 1150 2080 980 1000 1880 885 860 1740 820 755 1550 730 645
.30 75 2195 1035 1130 2030 960 975 1840 870 835 1710 805 750 1520 715 635
.40 100 2120 1000 1100 1970 930 960 1790 845 815 1665 785 730 1495 705 630
.50 125 2050 965 1080 1910 900 934 1745 825 800 1620 765 715 1460 690 620
.60 150 1985 935 1050 1840 870 905 1685 795 785 1565 740 705 1415 670 610
.70 175 1885 890 1020 1770 835 890 1635 765 775 1515 715 685 1370 645 595
.80 200 1815 855 1005 1690 800 860 1570 740 750 1450 685 670 1315 620 580
.90 225 1735 820 980 1615 760 835 1485 700 725 1385 655 655 1245 590 565
NOTE All air data is measured external to unit with 1 in. (25 mm) cleanable foam filter (not furnished) in place. Also see Filter Air Resistance table.
