Page 71
MATCH UP COMMENTS OR SEQUENCE
G32V−1 / −3 OPERATION SEQUENCE AND JUMPERS SUMMARY WITH VSP2 (COOLING)
Two-Speed Compressor,
no CCB1, no Harmony
Blower operates on low
speed heat/cool tap when
compressor is in first
stage cooling. Blower op-
erates on high speed cool
tap when compressor is in
second stage cooling.
DS" to Y2"
Single-Speed Com-
pressor, no CCB1,
no Harmony
Blower operates on high speed
cool tap during cooling.
(continued on following page)
FOR HEATING JUMPERS
SEE HEATING SECTION
ABOVE
G32V−1 / −3 OPERATION SEQUENCE AND JUMPERS SUMMARY WITH VSP2 (HEATING CONTINUED)
Two−Stage Heating
With Two−Stage
Thermostat
No
Jumpers
Two−Stage Blower operates on the low
speed heat/cool tap during first
stage heating. Blower operates
on high speed heat tap during
second stage heating.
MATCH UP
COMMENTS OR SEQUENCE
T−STRIP JUMPER
T−Strip
Jumper
Mode of
Operation
DS to Y1"
Move factory
wired jumper from
Y1 to Y2".
(continued from previous page)
(factory wired)
Jumper
Y1
Y2
Remove Jumper
DS to Y1"
Blower operates on low speed
heat/cool tap during cooling
To Next Page
