Lennox G40DF Series User Manual

Page 27
Blower Performance
NOTE − All air data is measured external to unit with 1 in. cleanable filter (not furnished − field provided) in place.
G40DF−48C−110 PERFORMANCE
External
Static
Pressure
in. w.g.
Air Volume / Watts at Different Blower Speeds
High
Medium−
High
Medium−
Low
Low
cfm Watts cfm Watts cfm Watts cfm Watts
0.00
2035 846 1790 712 1510 595 1225 477
0.05 2000 825 1760 694 1495 581 1225 470
0.10 1970
803 1730 675 1475 567 1220 463
0.15
1925 781 1710 657 1475 555 1220 455
0.20 1880 758 1685 638 1465 542 1215 447
0.25 1835 736 1655 618 1440 528 1200 437
0.30
1795 714 1625 597 1420 514 1185 427
0.40 1680 669 1550 564 1360 483 1135 400
0.50 1620
630 1445 524 1280 447 1065 371
0.60
1445 592 1310 479 1165 404 1000 343
0.70 1290 545 1180 434 1055 369 905 319
0.80 1155
502 1065 406 955 348 815 296
0.90
1010 472 930 372 840 320 690 265
G40DF−60C−110 PERFORMANCE
External
Static
Pressure
in. w.g.
Air Volume / Watts at Different Blower Speeds
High
Medium−
High
Medium−
Low
Low
cfm Watts cfm Watts cfm Watts cfm Watts
.00
2475 1276 2280 987 1995 845 1690 698
.10 2390 1248 2235 955 1990 829 1675 690
.20 2330
1223 2180 945 1975 809 1665 675
.30 2245 1192 2125 911 1940 786 1660 657
.40 2175 1187 2050 880 1895 757 1650 636
.50 2085 1145 1970 849 1835 734 1625 619
.60
2020 1129 1880 815 1750 695 1580 599
.70 1920 1094 1775 785 1660 669 1525 579
.80 1785 1052 1685 762 1585 645 1440 556
.90 1670 1020 1600 741 1520 633 1370 538
G40DF−60D−135 PERFORMANCE
External
Static
Pressure
in. w.g.
Air Volume / Watts at Different Blower Speeds
High Medium−High Medium−Low Low
cfm Watts cfm Watts cfm Watts cfm Watts
.00
2660 1379 2325 1059 1960 864 1655 684
.10 2560 1353 2310 1030 1945 840 1640 667
.20 2490 1325 2280 1000 1940 824 1630 661
.30 2415 1293 2225 972 1930 801 1625 649
.40 2345 1264 2170 941 1910 779 1620 638
.50 2265 1235 2115 918 1870 754 1615 624
.60 2165 1199 2020 880 1830 733 1585 604
.70 2050 1160 1940 854 1755 705 1570 604
.80 1955
1112 1865 828 1680 683 1515 584
.90 1865 1096 1760 797 1605 656 1465 567
