G40DF(X) Parts Arrangement
FIGURE 1
Blower Assembly
Blower Motor
Capacitor
Internal Flue Pipe
Assembly
Flue Box Gasket
Flue Collector Box
Gasket
Combustion Air Inducer
Gasket
Manifold
Burner
Gas Valve
Flame Rollout
Switches
Flame
Sensor
Primary
Limit
Igniter
Heat Exchanger
Igniter
Bracket
Combustion Air
Pressure Switch
Combustion
Air Orifice
Gas
Orifices
Transformer
Integrated Ignition
Control Board
Flue
Chase
Gasket
Door
Interlock Switch
