Page 8
BLOWER DATA
G50UH−36C−110 PERFORMANCE
External Static
Air Volume / Watts at Various Blower Speeds
Pressure
High Medium−High Medium−Low Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts
0.00 0 1555 735 715 1335 630 575 1085 510 460 925 435 365
0.05 12 1540 725 705 1330 630 555 1080 510 450 920 435 360
0.10 25 1525 720 690 1320 625 545 1075 505 440 915 430 355
0.15 37 1510 715 680 1310 620 535 1070 505 430 910 430 350
0.20 50 1490 705 670 1295 610 525 1065 505 420 900 425 340
0.25 62 1465 690 655 1280 605 510 1060 500 415 890 420 335
0.30 75 1440 680 645 1260 595 495 1050 495 405 880 415 330
0.40 100 1385 655 615 1230 580 485 1030 485 390 865 410 320
0.50 125 1320 625 590 1190 560 460 995 470 375 835 395 300
0.60 150 1260 595 570 1135 535 430 960 455 355 815 385 295
0.70 175 1190 560 545 1075 505 410 915 430 345 775 365 285
0.80 200 1090 515 515 970 460 385 860 405 325 760 360 280
0.90 225 975 460 485 880 415 360 790 375 305 705 335 275
NOTE − All air data is measured external to unit with 1 in. (25 mm) cleanable filter (not furnished − field provided) in place. Also see Filter Air Resistance table.
G50UH−48B−070 PERFORMANCE
External Static
Air Volume / Watts at Different Blower Speeds
Pressure
High Medium−High Medium−Low Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts
.00 0 2080 980 846 1810 855 764 1535 725 634 1295 610 519
.10 25 2030 955 810 1790 845 714 1520 715 600 1285 605 492
.20 50 1955 920 767 1760 830 675 1515 715 566 1275 600 477
.30 75 1885 890 732 1710 805 640 1505 710 555 1265 595 459
.40 100 1820 860 699 1670 790 611 1470 695 525 1255 590 443
.50 125 1740 820 664 1600 755 575 1420 670 496 1215 575 414
.60 150 1635 770 624 1530 720 544 1350 635 464 1175 555 400
.70 175 1545 730 597 1420 670 501 1270 600 432 1080 510 368
.80 200 1400 660 554 1295 610 462 1135 535 392 990 465 343
.90 225 1250 590 512 1125 530 419 1050 495 372 875 410 310
NOTES − All air data is measured external to unit with 1 in. (25 mm) cleanable filter (not furnished − field provided) in place. Also see Filter Air Resistance table.
Air volume based on bottom air return air. Actual air volume may vary on side return air applications.
G50UH−48B−090 PERFORMANCE
External Static
Air Volume / Watts at Various Blower Speeds
Pressure
High Medium−High Medium−Low Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts
0.00 0 1970 930 790 1810 855 735 1585 750 670 1340 630 565
0.05 12 1940 915 780 1785 840 715 1580 745 650 1335 630 555
0.10 25 1915 905 765 1760 830 695 1570 740 630 1325 625 540
0.15 37 1880 885 745 1730 815 660 1560 735 615 1325 625 530
0.20 50 1840 870 730 1700 800 620 1545 730 600 1320 625 520
0.25 62 1805 850 715 1670 790 625 1520 715 585 1310 620 510
0.30 75 1765 835 695 1640 775 625 1490 705 565 1295 610 500
0.40 100 1695 800 670 1570 740 595 1440 680 540 1260 595 480
0.50 125 1600 755 635 1490 705 560 1360 640 505 1195 565 450
0.60 150 1505 710 600 1400 660 530 1285 605 480 1140 540 425
0.70 175 1395 660 565 1265 595 485 1170 550 440 990 465 380
0.80 200 1250 590 520 1100 520 445 975 460 390 905 425 355
0.90 225 1005 475 460 870 410 385 900 425 365 810 380 325
NOTE − All air data is measured external to unit with 1 in. (25 mm) cleanable filter (not furnished − field provided) in place. Also see Filter Air Resistance table.
