Lennox GCS16-1853-235 User Manual

Page 11
GCS16823 BLOWER PERFORMANCE
Air
STATIC PRESSURE EXTERNAL TO UNIT  Inches Water Gauge
Ai
r
Volume
(f )
.20 .40 .60 .70 .80 .90 1.00 1.10 1.30 1.50
Volume
(cfm)
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
2200                 790 .75 835 .85 880 .90 920 1.00 960 1.10 1000 1.15 1075 1.35 1145 1.55
2400                 815 .85 860 .95 900 1.05 940 1.15 975 1.20 1015 1.30 1085 1.50 1160 1.70
2600         755 .80 840 1.00 880 1.10 920 1.20 960 1.30 995 1.40 1030 1.50 1100 1.70 1170 1.90
2800         790 .95 870 1.15 910 1.25 945 1.35 980 1.45 1020 1.55 1055 1.70 1120 1.90 1190 2.10
3000 740 .95 825 1.15 900 1.35 935 1.45 970 1.55 1005 1.65 1040 1.75 1075 1.90 1140 2.10        
3200 780 1.10 855 1.30 930 1.55 965 1.65 1000 1.75 1035 1.85 1065 2.00 1100 2.10                
3400 820 1.30 895 1.55 960 1.75 995 1.85 1030 2.00 1060 2.10 1095 2.25                        
NOTE  All data is measured external to the unit with dry coil and with the air filters in place. See Page 23 for Accessory Air Resistance data.
GCS16953 BLOWER PERFORMANCE
Air STATIC PRESSURE EXTERNAL TO UNIT  Inches Water Gauge
Volume .20 .40 .60 .70 .80 .90 1.00 1.10 1.30 1.50
(cfm) RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
2400                 860 .95 905 1.05 955 1.55 1000 1.25 1050 1.40 1100 1.55 1195 1.95 1285 2.25
2600                 885 1.10 930 1.20 970 1.30 1015 1.40 1060 1.55 1105 1.70 1200 2.15        
2800         830 1.05 910 1.25 955 1.35 995 1.45 1035 1.60 1075 1.70 1115 1.85 1210 2.25        
3000         860 1.20 945 1.45 980 1.55 1020 1.65 1060 1.80 1095 1.90 1135 2.05                
3200 835 1.20 905 1.40 975 1.60 1010 1.75 1050 1.90 1085 2.00                                
3400 880 1.40 945 1.60 1010 1.85 1045 2.00 1080 2.10                                        
3600 920 1.65 985 1.85 1050 2.10 1080 2.25                                                
3800 965 1.90 1025 2.15                                                                
NOTE  All data is measured external to the unit with dry coil and with the air filters in place. See Page 23 for Accessory Air Resistance data.
GCS161353 BLOWER PERFORMANCE
Air STATIC PRESSURE EXTERNAL TO UNIT  Inches Water Gauge
Volume .20 .40 .60 .70 .80 .90 1.00 1.10 1.30 1.50
(cfm) RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3600         672 1.14 740 1.36 772 1.47 802 1.60 831 1.74 860 1.87 887 2.00 940 2.30 985 2.60
3800         690 1.27 760 1.48 790 1.64 820 1.78 850 1.93 878 2.06 905 2.20 950 2.46 994 2.76
4000 642 1.18 715 1.43 778 1.67 809 1.81 838 1.95 866 2.09 895 2.24 920 2.38 968 2.66 1013 2.96
4200 670 1.35 736 1.50 798 1.87 828 2.00 856 2.13 885 2.28 913 2.43 938 2.56 984 2.86 1030 3.19
4400 693 1.52 760 1.79 821 2.06 850 2.29 878 2.36 905 2.50 930 2.63 955 2.77 1003 3.08        
4600 718 1.70 785 2.00 843 2.29 872 2.44 900 2.59 923 2.71 948 2.84 974 3.00 1021 3.32        
4800 747 1.93 807 2.22 865 2.41 892 2.66 918 2.82 940 2.93 970 3.09 995 3.25                
5000 772 2.16 830 2.46 887 2.76 915 2.92 940 3.07 965 3.24 989 3.43                        
5200 800 2.41 860 2.75 915 2.92 940 3.22 965 3.42                                        
NOTE  All data is measured external to the unit with dry coil and with the air filters in place. See Page 23 for Accessory Air Resistance data.
NOTE  Data in shaded area denotes optional 3 hp drive kit.
