Page 13
GCS161853330 BLOWER PERFORMANCE
STATIC PRESSURE EXTERNAL TO UNIT Inches Water Gauge
Air
Volume
cfm
.20 .40 .60 .70 .80 .90 1.00 1.10 1.30 1.50
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
5200 580 1.75 620 1.95 680 2.40 705 2.55 725 2.70 750 2.85 775 3.00 795 3.30 840 3.45 880 3.65
5400 590 1.90 640 2.15 695 2.55 715 2.75 740 2.85 765 2.95 785 3.10 810 3.35 850 3.55 890 3.80
5600 605 2.00 655 2.35 710 2.75 730 2.90 755 2.95 775 3.15 759 3.25 815 3.45 860 3.70 900 4.00
5800 615 2.20 670 2.50 720 2.90 740 3.10 765 3.15 785 3.30 810 3.50 830 3.60 870 3.80 910 4.10
6000 630 2.35 690 2.70 730 3.10 755 3.25 775 3.40 795 3.60 820 3.65 840 3.80 880 4.10 920 4.30
6200 650 2.55 705 2.95 750 3.35 770 3.50 790 3.55 810 3.75 830 3.90 850 4.00 890 4.35 930 4.80
6400 670 2.75 720 3.25 760 3.50 780 3.65 800 3.75 820 4.00 845 4.10 865 4.20 900 4.50 940 4.95
6600 690 3.15 730 3.55 775 3.75 795 3.85 810 4.05 835 4.15 855 4.30 875 4.45 910 4.75 950 5.15
6800 705 3.20 750 3.75 790 4.00 805 4.10 825 4.30 845 4.45 865 4.55 885 4.70 925 5.05 965 5.45
7000 720 3.60 760 3.95 800 4.30 820 4.45 840 4.55 860 4.75 880 4.95 895 5.05 935 5.35
7200 740 3.85 775 4.10 810 4.50 830 4.65 850 4.80 870 4.95 890 5.05 905 5.35 945 5.70
7400 755 3.95 790 4.25 825 4.65 845 4.75 865 4.90 885 5.15 900 5.35 930 5.65
7600 765 4.20 800 4.40 830 4.80 850 4.90 870 5.15 890 5.40 905 5.60
NOTE All data is measured external to the unit with dry coil and with the air filters in place. See Page 23 for Accessory Air Resistance data.
NOTE Data in shaded area denotes optional 5 hp drive kit.
