Page 16
GCS163003235 BLOWER PERFORMANCE
Air
STATIC PRESSURE EXTERNAL TO UNIT  Inches Water Gauge
Air
Volume
(f )
.20 .40 .60 .80 1.00 1.20 1.40 1.60 1.80 2.00
Volume
(cfm)
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
6750 450 1.50 505 2.00 560 2.50 600 2.80 640 3.20 680 3.50 710 4.00 740 4.50 770 4.85 800 5.15
7000 465 1.70 515 2.20 565 2.70 610 3.05 650 3.40 685 3.80 720 4.30 745 4.70 775 5.05 810 5.35
7250 480 2.00 525 2.30 575 2.80 620 3.15 660 3.55 690 4.00 725 4.55 750 4.90 780 5.30 820 5.50
7500 490 2.20 540 2.55 585 3.00 625 3.35 665 3.80 700 4.20 730 4.75 760 5.15 790 5.55 825 5.80
7750 505 2.40 550 2.80 590 3.15 635 3.55 670 4.00 705 4.40 740 5.00 770 5.40 800 5.75 835 6.05
8000 515 2.60 580 3.00 605 3.40 640 3.70 680 4.20 715 4.75 745 5.30 780 5.80 810 6.00 840 6.40
8250 530 2.80 575 3.25 615 3.60 650 4.00 685 4.50 725 5.15 755 5.55 790 6.05 820 6.25 850 6.70
8500 540 3.10 585 3.45 625 3.90 660 4.35 695 4.75 730 5.40 765 5.90 800 6.30 825 6.55 855 6.90
8750 560 3.30 600 3.75 635 4.10 670 4.60 705 5.10 740 5.75 775 6.25 805 6.50 835 6.80 860 7.25
9000 570 3.60 610 3.95 645 4.40 680 4.90 715 5.45 750 6.10 785 6.60 810 6.80 840 7.20 865 7.60
9250 580 3.85 625 4.25 650 4.70 690 5.25 725 5.90 760 6.45 795 6.90 820 7.10 850 7.60 875 7.90
9500 600 4.25 635 4.55 665 5.20 700 5.60 740 6.25 770 6.85 805 7.15 825 7.40 855 7.85 880 8.75
9750 610 4.40 640 4.90 675 5.35 710 5.90 745 6.60 780 7.20 810 7.45 840 7.75 860 8.25 890 8.75
10,000 625 4.80 655 5.20 690 5.75 720 6.40 760 6.90 790 7.50 815 7.70 845 8.15 870 8.60 905 9.20
10,250 635 5.10 665 5.60 700 6.10 735 6.75 770 7.40 800 7.80 820 8.00 855 8.50 880 9.00        
10,500 645 5.50 680 6.00 710 6.60 745 7.20 780 7.85 810 8.20 830 8.40 860 8.90 890 9.50        
10,750 660 5.80 690 6.40 725 7.00 755 7.60 790 8.15 815 8.30 840 8.60 870 9.40 900 9.90        
11,000 670 6.20 705 6.75 735 7.40 765 8.00 800 8.50 820 8.70 850 9.25 880 9.75                
11,250 685 6.60 720 7.35 745 7.85 780 8.50 810 7.85 830 9.15 860 9.50 890 10.30                
11,500 700 7.15 730 7.75 760 8.35 790 8.80 815 9.10 840 9.60 870 10.25 900 10.90                
11,750 710 7.40 740 8.20 770 8.75 800 9.20 820 9.55 850 10.10 880 10.80                        
12,000 725 8.10 755 8.75 785 9.25 810 9.60 835 10.00 860 10.60                                
12,250 740 8.60 765 9.20 800 9.70 820 10.00 845 10.60 870 11.20                                
12,500 750 9.15 780 9.70 810 10.10 830 10.50 860 11.10                                        
NOTE  All data is measured external to the unit with the air filter in place.
GCS163003470 BLOWER PERFORMANCE
Air
STATIC PRESSURE EXTERNAL TO UNIT  Inches Water Gauge
Air
Volume
(f )
.20 .40 .60 .80 1.00 1.20 1.40 1.60 1.80 2.00
Volume
(cfm)
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
6750 465 1.90 510 2.00 550 2.40 590 2.70 630 3.10 660 3.35 700 3.80 730 4.20 760 4.55 790 4.85
7000 475 1.90 520 2.20 560 2.60 600 2.90 640 3.25 670 3.60 705 4.00 740 4.40 770 4.75 800 5.25
7250 490 2.00 535 2.40 580 2.80 610 3.10 650 3.50 680 4.10 715 4.25 750 4.65 780 5.10 810 5.60
7500 500 2.20 540 2.60 585 3.00 620 3.25 660 3.70 690 4.20 725 4.55 760 4.90 785 5.40 820 6.00
7750 515 2.40 560 2.80 600 3.20 640 3.60 670 4.00 700 4.40 735 4.75 765 5.20 795 5.75 830 6.40
8000 530 2.70 570 3.10 610 3.40 645 3.80 680 4.25 710 4.70 745 5.10 775 5.50 805 6.10 840 6.70
8250 545 2.90 585 3.30 620 3.65 660 4.00 690 4.50 720 4.95 755 5.40 785 5.80 815 6.40 845 7.00
8500 560 3.20 600 3.50 635 3.85 670 4.40 700 4.85 735 5.30 765 5.75 795 6.25 825 6.80 855 7.30
8750 570 3.40 610 3.80 645 4.20 680 4.70 710 5.20 745 5.60 775 6.10 805 6.60 835 7.10 865 7.70
9000 585 3.70 625 4.10 660 4.50 690 5.05 720 5.50 755 5.90 785 6.50 820 7.05 845 7.55 875 8.05
9250 600 3.90 640 4.40 675 4.90 705 5.40 740 5.85 770 6.40 800 6.80 830 7.50 855 7.90 880 8.50
9500 615 4.25 650 4.70 685 5.30 720 5.75 750 6.25 780 6.80 810 7.30 840 7.80 865 8.30 890 8.90
9750 630 4.60 665 5.10 700 5.70 730 6.20 760 6.60 790 7.20 820 7.75 850 8.25 885 8.90 905 9.40
10,000 645 4.60 680 5.50 710 6.00 745 6.60 775 7.20 800 7.60 830 8.20 860 8.60 890 9.20 915 9.85
10,250 660 5.30 695 5.90 720 7.40 760 6.95 785 7.55 820 8.10 845 8.60 870 9.05 900 9.75 935 10.60
10,500 675 5.75 705 6.30 740 6.85 770 7.40 800 7.90 830 8.60 855 8.90 880 9.50 915 10.35 940 10.90
10,750 690 6.25 720 6.70 755 7.30 780 7.80 810 8.40 840 8.95 865 9.40 890 9.90 920 10.75 945 11.30
11,000 705 6.65 735 7.20 765 7.70 795 8.25 825 8.90 850 9.35 880 9.80 905 10.50 930 11.20        
11,250 715 7.00 750 7.70 780 8.30 810 8.85 840 9.35 960 9.80 890 10.40 915 11.00                
11,500 730 7.50 760 8.20 795 8.75 820 9.35 850 9.85 875 10.35 900 11.00                        
11,750 745 8.10 775 8.65 810 9.25 840 9.80 880 10.25 885 10.80                                
12,000 760 8.55 790 9.20 820 9.75 850 10.35 875 10.80 900 11.50                                
12,250 775 9.10 805 9.70 835 10.25 860 10.80 885 11.40                                        
12,500 790 9.75 820 10.25 845 10.75 870 11.30                                                
NOTE  All data is measured external to the unit with the air filter in place.
