• 10 •
GAM
SRE
Installation, operation and maintenance / INALTO-IOM-1809-E
Sizes 49 & 57
x4 Screw TC+M5x12 UNI7687
x4 Hex nut M5 fl anged with corrugated washer DIN4161
Size 05 to 28
x8 Screw TC+M5x12 UNI7687
x6 Hex nut M5 fl anged with corrugated washer DIN4161
Sizes 49 & 57
x10 Screw TC+M5x12 UNI7687
x6 Hex nut M5 fl anged with corrugated washer DIN4161
Figure 13
Figure 14
ASSEMBLY DIAGRAMS
