MODEL : SVHS 36/0 36/0 36/0 36/0 48/1 70V 36/0 48/1
Mod. 0201/0205 0251 0261 0271 0301 0401 0272 0302
V/Ph/Hz 230 V / 1 Ph / 50 Hz
m3/h 8400 9000 12000 18000 9000
W 720 420 560 1125 420
A 3.4 0.2 6 5 1 2.0
Nr. 4 6 8 3 6
Ø 350 350 630 350 350
dB(A)
46 39 46 38 39
L mm 1853 2408 3393 1853 2408
P mm 1150 1150 1110 1150 1150
H mm 863 1270 863 863 863
L mm 2408 3373 1853 2408 1298
P mm 380 380 705 380 380
H mm 1130 1130 1040 1130 1130
kg 81 104 226 81 104
Page 32 - Application Guide INNOV@-0907
Tab.17 - Remote Condenser - Low Noise Execution - SHVS
L = Lenght, P = Depth, H = Heigh
TECHNICAL DATA
Tab.18 - Remote Condenser - Low Noise Execution - SHVS
MODEL : SVHS 48/1 70V 70V 87V 87V 97V 97V 111V
Model Mod. 0362 0422 0452 0512 0552 0602 0692 0762
Power supply V/Ph/Hz 230 V / 1 Ph / 50 Hz
Air ow m3/h 12000 18000 24000 22400 30000
Absorbed power W 560 1125 1500 1500 1875
Absorbed current A 2.6 5.1 6.8 6.8 8.5
Fans Nr. 8 3 4 4 5
Ø 350 630
Sound pressure level
dB(A)
39 46 47 47 48
Dimensions L mm 2408 3393 4393 4393 5393
[vertical air ow] P mm 1150 1110 1110 1110 1110
H mm 1270 1270 1270 1270 863
Dimensions L mm 3373 3373 4373 5373 1298
[horizontal air ow] P mm 380 705 705 705 705
H mm 1130 1040 1040 1040 1040
Weight kg 104 226 298 328 355
L = Lenght, P = Depth, H = Heigh
Model
Power supply
Air ow
Absorbed power
Absorbed current
Fans
Sound pressure level
Dimensions
[vertical air ow]
Dimensions
[horizontal air ow]
Weight
