Application Guide INNOV@-0907- Page 43
DHAUR
0201 0205 0251 0261 0271 0301 0401 0272 0302 0362 0422 0452 0512 0552 0602 0692 0762
A 170 182 193
B 74 74 85
C 270 251,5 252
D 250 202,5 203
E 444 444 624
F 610 1000
G 536 726
1" - Φ 16 1" - Φ 16 1" - Φ 16
1" 1/4 - Φ 18 1" 1/4 - Φ 18 1" 1/4 - Φ 18
1 2 3
1010 1750 2510
Direct Expansion DX unit : DHAUR
OVERALL DIMENSIONS
FRONT VIEW FRONT VIEW
LATERAL VIEW
A-A CROSS VIEW
Lenght
Liquid line inlet
Gaz line outlet
Frame
Length
Cooling Water Inlet
Cooling Water Outlet
Humidier Water Supply
Humidier Water Drain
