M
HP
M
MM
HP
LPLP
Page 52 - Application Guide INNOV@-0907
DX UNIT (2COMPRESSOR)
REFRIGERATION DIAGRAM
REF DESCRIPTION REF DESCRIPTION
1 Compressor 8 Evaporator
2 High pressure switch [HP] 9 Low pressure switch [LP]
3 Pressure probe [Opt.] 10 Liquid receiver
4 Ball valve 11 Condenser
5 Filter dryer 12 Flooding valve
6 Sight glass 13 Safety valve
7 Thermostatic valve 14 Check valve
SUPPLY LIMIT SUPPLY LIMIT
OPTIONAL OPTIONAL
