Lennox LC22 User Manual

CONTENTS
1
Page
Compact Waterside Fan Coil Specification 2
Mounting 3
Pipework Connections 3
Duct Connections 3
Electrical Connections 4
Controls 4
Fan Speed Settings 5
Periodic Maintenance 6
Electrical Data 7
Coil Water Content 7
Weights 7
Minimum No. Spigots 7
Coil Connections 7
General Arrangement Drgs
Unit Ref: Drg Ref:
LC22 Z304255 (2 pages) 13-14
LC31 Z304256
LC45 Z304257
LC60 Z304258
LC76 Z304259
Example Wiring Diagrams 8-12
(2 pages) 15-16
(2 pages) 17-18
(2 pages) 19-20
(2 pages) 21-22
R
LENN X
EUROVENT
CERTIFIED PERFORMANCE
Manufacturer reserves the right to change any product specifications without notice.

Lennox LC22 Specifications

General

Brand	Lennox
Model	LC22
Category	Air Conditioner
Language	English
