FIGURE 15
ELECTRIC HEAT VESTIBULE PARTS ARRANGEMENT
TERMINAL STRIP
(TB3)
FIRST STAGE ELECTRIC
HEAT CONTACTOR K15
SECOND STAGE ELECTRIC
HEAT CONTACTOR K16
FIRST HEAT SECTION (LEFT SIDE)
SECOND HEAT SECTION (RIGHT SIDE)
FUSE F3
FUSE F3
TERMINAL STRIP
(TB3)
FIRST STAGE ELECTRIC
HEAT CONTACTOR K17
SECOND STAGE ELECTRIC
HEAT CONTACTOR K18
FUSE F3
FUSE F3
