Page 42
4
FIGURE 23
REHEAT MODE REFRIGERANT ROUTING
210, 240 AND 300 UNITS
REHEAT
COIL
CONDENSER COIL
CIRCUIT 2 & 4 ARE
INTERTWINED
1
2
EXPANSION
VALVES
CHECK
VALVE
L14
REHEAT
VALVE
L30
REHEAT
VALVE
3
CHECK
VALVE
ALL FOUR
EVAPORATOR
COILS ARE
INTERTWINED
Note: Two refrigerant circuits are shown;
both circuits operate during reheat.
CONDENSER COIL
CIRCUIT 1 & 3 ARE
INTERTWINED
4
FIGURE 24
COOLING MODE REFRIGERANT ROUTING
210, 240 AND 300 UNITS
REHEAT
COIL
1
2
EXPANSION
VALVES
CHECK
VALVE
L14
REHEAT
VALVE
L30
REHEAT
VALVE
3
CHECK
VALVE
Note: Two refrigerant circuits are
shown; both circuits operate
when there is a cooling demand.
CONDENSER COIL
CIRCUIT 2 & 4 ARE
INTERTWINED
ALL FOUR
EVAPORATOR
COILS ARE
INTERTWINED
CONDENSER COIL
CIRCUIT 1 & 3 ARE
INTERTWINED
