LHT/LDT122, 150H DIMENSIONS - GAS HEAT SECTION SHOWN
END VIEW
60−1/8
(1527)
58−1/8
46−7/8
(1191)
3−1/2
(89)
43−3/8
(1102)
(1476)
SIDE VIEW
(Horizontal Openings)
HORIZONTAL
RETURN AIR
OPENING
HORIZONTAL
SUPPLY AIR
OPENING
CONDENSATE
DRAIN (BACK)
5−3/8
(137)
6−1/8
(156)
12−1/8
(308)
1−5/8
(41)
54−5/8
(1387)
89−1/2
(2273)
(762)
(762)
(394)
15−1/2
(394)
30
15−1/2
30
BASE
60−1/8 (1527)
TOP VIEW
BOTTOM RETURN
AIR OPENING
24
(610)
5−5/8
(143)
6−1/8
(156)
6−1/8
(156)
6−5/8
(168)
28
(711)
27
(686)
20
(508)
BOTTOM
CONDENSATE
124−3/8
(3159)
BOTTOM SUPPLY
AIR OPENING
34−7/8
(886)
BASE
(273)
10−3/4
7 (178)
7 (178)
BOTTOM
POWER ENTRY
5−1/2 (140) Dia.
SIDE VIEW
LIFTING HOLES
(FOR RIGGING)
124−3/8
(3159)
123−1/8
(3127)
OPTIONAL DISCONNECT
(FACTORY INSTALLED)
5/8
(16)
34−7/8
(886)
5−3/8
(137)
46−7/8
(1191)
FORKLIFT SLOTS
(BOTH SIDES)
CONDENSATE
DRAIN (FRONT)
ELECTRIC
INLETS
18-1/2
GAS SUPPLY
INLET
39-7/8
(1013)
OUTLET
FLUE
