Page 4
LHT078, 092, 102, 120, 150 PARTS ARRANGEMENT
UNIT
CONTROLLER
INDOOR
COIL
OUTDOOR FANS
(3 ON 122 & 150)
OUTDOOR
COIL
COMPRESSORS
CONDENSATE
DRAIN
FILTERS
(FOUR - 20 X 25 X 2”)
ECONOMIZER
(OPTIONAL)
BLOWER
(DIRECT DRIVE)
ELECTRIC HEAT
(OPTIONAL)
WIRELESS
BOARD
WIFI
ANTENNA
REVERSING
VALVE
LDT078, 092, 102, 120, 150 PARTS ARRANGEMENT
UNIT
CONTROLLER
INDOOR
COIL
OUTDOOR FANS
(3 ON 122 & 150)
OUTDOOR
COIL
COMPRESSORS
CONDENSATE
DRAIN
FILTERS
(FOUR - 20 X 25 X 2”)
ECONOMIZER
(OPTIONAL)
BLOWER
(DIRECT DRIVE)
GAS VALVE
BURNERS
COMBUSTION
AIR INDUCER
IGNITION
CONTROL
WIRELESS
BOARD
WIFI
ANTENNA
REVERSING
VALVE
