Page 36
EVAPORATOR
COIL
STAGE 1
CONDENSER COIL
FIGURE 8
STAGE 2
CONDENSER COIL
STAGE 1
EVAPORATOR
COIL
STAGE 2
EVAPORATOR
COIL
CAV REFRIGERANT CIRCUITS
VAV UNIT REFRIGERANT CIRCUITS
STAGE 1
CONDENSER COIL
FIGURE 9
STAGE 2
CONDENSER COIL
STAGE 1
EVAPORATOR
COIL
STAGE 2
EVAPORATOR
COIL
CIRCUIT 3
CIRCUIT 4
