Lennox LGA060 Unit Information

Page 10
BELTDRIVE BLOWER DATA
FACTORY INSTALLED BELT DRIVE KIT SPECIFICATIONS
Motor Outputs RPM Range
Nominal hp Maximum hp Nominal kW Maximum kW Drive 1 Drive 2 Drive 3 Drive 4
Standard or High Efficiency - 1.5 1.72 1.1 1.3 615 - 920 800 - 1105 - - - - - - - -
Standard or High Efficiency - 2 2.3 1.5 1.7 - - - - - - - - 920 - 1230 - - - -
Standard Efficiency Only - 3 3.45 2.2 2.6 - - - - - - - - - - - - 1070 - 1325
*Using total air volume and system static pressure requirements determine from blower performance tables rpm and motor output required. Maximum usable output of motors
furnished by Lennox are shown. In Canada, nominal motor output is also maximum usable motor output. If motors of comparable output are used, be sure to keep within the
service factor limitations outlined on the motor nameplate.
DIRECTDRIVE BLOWER DATA
LGA/LCA036-060 DIRECT DRIVE BLOWER PERFORMANCE @ 208 VOLTS (Downflow)
E
x
t
e
r
n
a
l
S
t
a
t
i
c
P
r
e
s
s
u
r
e
Air Volume at Various Blower Speeds
E
x
t
e
r
n
a
l
S
t
a
t
i
c
P
r
e
s
s
u
r
e
High Medium-High Medium Medium-Low Low
in. w.g. Pa cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s
0 0 2530 1195 2265 1070 1970 930 1720 810 1440 680
.10 25 2495 1175 2235 1055 1945 920 1700 800 1430 675
.20 50 2450 1155 2200 1040 1915 905 1670 790 1415 670
.30 75 2405 1135 2160 1020 1880 890 1640 775 1390 655
.40 100 2355 1110 2115 1000 1840 870 1605 755 1360 640
.50 125 2300 1085 2065 975 1795 845 1565 740 1330 630
.60 150 2235 1055 2010 950 1745 825 1515 715 1290 610
.70 175 2165 1020 1945 920 1690 800 1460 690 1245 590
.80 200 2090 985 1875 885 1620 765 1400 660 1195 565
.90 225 2000 945 1790 845 1550 730 1330 630 1130 535
1.00 250 1895 895 1695 800 1460 690 1250 590 1055 500
1.10 275 1770 835 1580 745 1360 640 1160 545 975 460
1.20 300 1620 765 1440 680 1240 585 1055 500 870 410
NOTE — All air data is measured external to unit with 2 row dry coil and 2 inch (51 mm) filters.
LGA/LCA036-060 DIRECT DRIVE BLOWER PERFORMANCE @ 230 VOLTS (Downflow)
E
x
t
e
r
n
a
l
S
t
a
t
i
c
P
r
e
s
s
u
r
e
Air Volume at Various Blower Speeds
E
x
t
e
r
n
a
l
S
t
a
t
i
c
P
r
e
s
s
u
r
e
High Medium-High Medium Medium-Low Low
in. w.g. Pa cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s
0 0 2750 1300 2500 1180 2245 1060 1955 925 1630 770
.10 25 2705 1275 2470 1165 2215 1045 1925 910 1600 755
.20 50 2650 1250 2430 1145 2180 1030 1890 890 1570 740
.30 75 2585 1220 2390 1130 2140 1010 1850 875 1535 725
.40 100 2535 1195 2340 1105 2100 990 1810 855 1500 710
.50 125 2475 1170 2290 1080 2050 965 1760 830 1455 685
.60 150 2405 1135 2225 1050 1995 940 1705 805 1405 665
.70 175 2330 1100 2155 1015 1930 910 1640 775 1365 645
.80 200 2245 1060 2075 980 1865 880 1575 745 1310 620
.90 225 2155 1015 1975 930 1780 840 1495 705 1240 585
1.00 250 2050 965 1860 880 1690 800 1405 665 1150 545
1.10 275 1935 915 1720 810 1585 750 1290 610 1040 490
1.20 300 1805 850 1560 735 1450 685 1160 545 915 430
NOTE — All air data is measured external to unit with 2 row dry coil and 2 inch (51 mm) filters.
LGA/LCA036-060 DIRECT DRIVE BLOWER PERFORMANCE @ 460/575 VOLTS (Downflow)
E
x
t
e
r
n
a
l
S
t
a
t
i
c
P
r
e
s
s
u
r
e
Air Volume at Various Blower Speeds
E
x
t
e
r
n
a
l
S
t
a
t
i
c
P
r
e
s
s
u
r
e
High Medium Low
in. w.g. Pa cfm L/s cfm L/s cfm L/s
0 0 2820 1330 2460 1160 1975 930
.10 25 2770 1305 2430 1145 1950 920
.20 50 2720 1285 2395 1130 1920 905
.30 75 2670 1260 2345 1105 1885 890
.40 100 2610 1230 2310 1090 1845 870
.50 125 2545 1200 2260 1065 1800 850
.60 150 2475 1170 2200 1040 1755 830
.70 175 2400 1130 2140 1010 1700 800
.80 200 2315 1090 2065 975 1635 770
.90 225 2220 1045 1980 935 1565 740
1.00 250 2115 1000 1880 885 1480 700
1.10 275 2000 945 1760 830 1370 647
1.20 300 1860 875 1615 760 1260 595
NOTE — All air data is measured external to unit with 2 row dry coil and 2 inch (51 mm) filters.
