LGA/LCA PLUMBING COMPONENTS
FIGURE 7
LOW PRESSURE
SWITCH (S87)
SCROLL COMPRESSOR (B1)
LOW AMBIENT
SWITCH (S11)
LIQUID LINE
SERVICE VALVE
CRANKCASE HEATER
(HR1)
HIGH PRESSURE
SWITCH (S4)
DISCHARGE LINE
SERVICE VALVE
PRESSURE TAP
RECIPROCATING COMPRESSOR
(B1)
LOW PRESSURE
SWITCH (S87)
LOW AMBIENT
SWITCH (S11)
LIQUID LINE
SERVICE VALVE
HIGH PRESSURE
SWITCH (S4)
DISCHARGE LINE
SERVICE VALVE
PRESSURE TAP
