Page 6
FIGURE 8
INSTALL HOODS
INTAKE
EXHAUST
PIVOT
BRACKET
MULLION
UNIT TOP
SIDE VIEW
HOOD
CAULK
CAULK
LOWER HOOD INSTALLED
ONLY WHEN ECONOMIZER IS
EQUIPPED WITH A GED
