LGH/LCH036, 048, 060, 072
TABLE 9
LGH/LCH048S NORMAL OPERATING PRESSURES - ALL-ALUMINUM COIL
Outdoor Coil Entering Air Temperature
65 F 75 F 85 F 95 F 105 F 115 F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
117 249 120 287 122 330 124 381 126 435 129 493
124 253 128 291 131 332 133 386 135 441 138 499
141 272 145 306 149 345 152 393 155 448 157 515
160 300 163 332 167 367 172 415 176 465 179 520
TABLE 10
LGH/LCH048H NORMAL OPERATING PRESSURES - ALL-ALUMINUM COIL
Outdoor Coil Entering Air Temperature
65 F 75 F 85 F 95 F 105 F 115 F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
116 251 119 289 121 331 124 377 126 429 129 488
123 256 127 293 130 335 132 382 135 435 137 494
139 277 143 308 148 348 151 395 155 447 158 503
156 306 161 338 165 373 170 416 174 468 178 523
TABLE 11
LGH/LCH060S NORMAL OPERATING PRESSURES - ALL-ALUMINUM COIL
Outdoor Coil Entering Air Temperature
65 F 75 F 85 F 95 F 105 F 115 F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
114 249 116 287 119 330 121 376 123 425 127 482
122 250 124 290 127 333 129 379 132 435 135 492
140 258 143 293 145 343 148 392 151 449 154 508
158 274 162 311 166 356 169 398 173 462 175 520
TABLE 12
LGH/LCH060H NORMAL OPERATING PRESSURES - ALL-ALUMINUM COIL
Outdoor Coil Entering Air Temperature
65 F 75 F 85 F 95 F 105 F 115 F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
113 240 116 285 117 329 119 383 120 454 122 533
122 245 125 285 127 322 129 376 130 431 132 516
141 254 143 293 146 334 149 382 151 436 153 498
159 269 163 305 167 351 169 395 172 448 176 507
TABLE 13
LGH/LCH072H NORMAL OPERATING PRESSURES - ALL-ALUMINUM COIL
Outdoor Coil Entering Air Temperature
65 F 75 F 85 F 95 F 105 F 115 F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
113 261 115 300 116 347 118 402 119 492 123 512
122 266 124 307 126 349 126 402 128 467 132 518
140 277 143 316 145 360 147 411 149 472 151 540
159 291 161 329 164 375 168 423 172 478 174 537
