SETTINGS > INSTALL > NEW M2
Use SETTINGS > INSTALL > NEW M2 to go through the setup and change settings as needed when installing a
replacement M2 (new M2 units have no factory pre-sets).
! SET !
Y/N
! SET !
! SET !
! SET !
NEW M2
M2 RESET
INSTALL
AFTER RESET, RETURN TO SETTINGS > INSTALL > NEW M2 AND SCROLL TO
CATALOG NO. AND CONTINUE CONFIGURING THE BOARD TO MATCH THE UNIT.
CLEAR ARE YOU
ALL SURE?
CONFIGURATIONS
UNIT SERIAL NO. XXXXXXXXX UNIT NO. XXX MODEL NO. XXXXXXXXXXXX
CATALOG NO. XXXXX
NOT INSTALLED
DAMPER MOAD
ECON
WHEN INSTALLING A NEW M2, ENTER THE SERIAL, UNIT NO.
AND MODEL NO. THE M2 WILL AUTOMATICALLY RESET.
! SET !
Use
arrows
to
move
THIS MENU ITEM IS ONLY VISIBLE AS A SELECTION WHEN
THE BLOWER CONTROL MODE IS SET FOR MSAV(ECTO
0.01 = 3) OR "M" IN BLOWERTYPE OF MODEL NUMBER.
EXHAUST NOT INSTALLED
STAGES 1 EXHAUST STAGE
2 EXHAUST STAGES
HUMIDITROL NO
YES
PHASE/VOLTAGE NOT INSTALLED
DETECTION INSTALLED
MSAV/VFD AUTOMATIC
BYPASS MANUAL
NONE
! SET !
SMARTAIRFLOW INSTALLED
NOT INSTALLED
