Lennox LGH Series Installation Instructions

Page 4
LGH/LCH036, 048, 060, 072, 074
LGH036, 048, 060, 074U PARTS ARRANGEMENT
EVAPORATOR
COIL
CONDENSER
FAN
CONDENSER
COIL
COMPRESSOR
CONDENSATE
DRAIN
FILTERS (4)
20 X 20 X 2”
ECONOMIZER
(OPTIONAL)
GAS VALVE 1
(4-STG. GAS
HEAT SHOWN)
BURNERS
COMBUSTION
AIR INDUCER
TXV
UNIT
CONTROLLER
BLOWER
COIL
GUARDS
(OPTIONAL)
GAS VALVE 2
(4-STG. GAS
HEAT SHOWN)
LCH036, 048, 060, 074U PARTS ARRANGEMENT
EVAPORATOR
COIL
CONDENSER
FAN
CONDENSER
COIL
COMPRESSOR
CONDENSATE
DRAIN
FILTERS (4)
20 X 20 X 2”
ECONOMIZER
(OPTIONAL)
TXV
UNIT
CONTROLLER
BLOWER
COIL
GUARDS
(OPTIONAL)
ELECTRIC
HEAT
