TABLE 4 581027-01
LGM/LCM092U No Reheat
Outdoor
Coil
Entering
Air Temp
CIRCUIT 1 CIRCUIT 2
Dis
charge
+
10 psig
Suction
+
5 psig
Dis
charge
+
10 psig
Suction
+
5 psig
655 F 252 140 269 137
755 F 293 143 311 139
855 F 335 146 354 142
955 F 382 148 403 144
1055 F 434 150 454 147
1155 F 490 153 508 150
TABLE 5 581028-01
LGM/LCM092U Reheat
Outdoor
Coil
Entering
Air Temp
Circuit 1 Circuit 2
Dis
charge
+
10 psig
Suction
+
5 psig
Dis
charge
+
10 psig
Suction
+
5 psig
655 F 258 140 269 136
755 F 301 139 308 137
855 F 344 141 349 139
955 F 392 143 398 142
1055 F 445 145 447 144
1155 F 504 148 501 147
TABLE 6 581029-01
LGM/LCM102U No Reheat
Outdoor
Coil
Entering
Air Temp
Circuit 1 Circuit 2
Dis
charge
+
10 psig
Suction
+
5 psig
Dis
charge
+
10 psig
Suction
+
5 psig
655 F 256 140 259 139
755 F 294 143 300 141
855 F 333 147 341 143
955 F 381 149 388 146
1055 F 433 151 438 149
1155 F 487 155 491 153
TABLE 7 581030-01
LGM/LCM102U Reheat
Outdoor
Coil
Entering
Air Temp
Circuit 1 Circuit 2
Dis
charge
+
10 psig
Suction
+
5 psig
Dis
charge
+
10 psig
Suction
+
5 psig
655 F 264 140 266 137
755 F 301 139 300 139
855 F 349 141 341 141
955 F 399 144 390 144
1055 F 450 146 440 147
1155 F 508 149 494 150
TABLE 8 581031-01
LGM/LCM120U No Reheat
Outdoor
Coil
Entering
Air Temp
Circuit 1 Circuit 2
Dis
charge
+
10 psig
Suction
+
5 psig
Dis
charge
+
10 psig
Suction
+
5 psig
655 F 258 132 263 131
755 F 296 137 302 133
855 F 337 139 344 135
955 F 383 141 389 137
1055 F 439 142 438 140
1155 F 490 145 494 143
TABLE 9 581032-01
LGM/LCM120U Reheat
Outdoor
Coil
Entering
Air Temp
Circuit 1 Circuit 2
Dis
charge
+
10 psig
Suction
+
5 psig
Dis
charge
+
10 psig
Suction
+
5 psig
655 F 272 131 255 133
755 F 309 135 294 135
855 F 350 138 335 137
955 F 396 139 381 139
1055 F 452 141 430 142
1155 F 503 144 485 145
TABLE 10 581033-01
LGM/LCM150U No Reheat
Outdoor
Coil
Entering
Air Temp
Circuit 1 Circuit 2
Dis
charge
+
10 psig
Suction
+
5 psig
Dis
charge
+
10 psig
Suction
+
5 psig
655 F 267 122 270 113
755 F 308 128 313 120
855 F 355 133 363 127
955 F 399 136 407 130
1055 F 448 139 456 132
1155 F 503 142 510 136
TABLE 11 581034-01
LGM/LCM150U Reheat
Outdoor
Coil
Entering
Air Temp
CIRCUIT 1 CIRCUIT 2
Dis
charge
+
10 psig
Suction
+
5 psig
Dis
charge
+
10 psig
Suction
+
5 psig
655 F 313 123 259 113
755 F 353 129 302 121
855 F 401 134 351 127
955 F 445 137 396 130
1055 F 493 140 445 133
1155 F 548 143 499 137
