Page 51
TABLE 13
MINIMUM AND MAXIMUM CFM
Gas Heat Minimum CFM
Unit Gas Heat Size
Airflow
CFM*
LGT092H-150H Standard 2150
LGT092H-150H Medium 2550
LGT092H-150H High 2600
IX-Staged Supply Air Operation
This is a summary of cooling operation for both belt and di
rect drive blowers.
Note - During a dehumidification demand the blower oper
ates at the highest speed. Free cooling is locked-out during
reheat operation. Refer to Hot Gas Reheat start-up and op
eration section for details.
A-Two-Stage Thermostat
1-Economizer With Outdoor Air Suitable
Y1 Demand -
Compressors Off
Blower Cooling Low
Dampers modulate to maintain 55° supply air
Y2 Demand -
Compressors Off
Blower Cooling High
Dampers Modulate to maintain 55° supply air
Note - If dampers are at maximum open for three minutes,
compressor 1 is energized and blower stays on cooling
high.
2-No Economizer or Outdoor Air Not Suitable
Y1 Demand -
Compressor 1 On
Blower Cooling Low
Y2 Demand -
Compressor 1 and 2 On
Blower Cooling High
B-Three-Stage Thermostat OR Zone Sensor
1-Economizer With Outdoor Air Suitable
Y1 Demand -
Compressors Off
Blower Cooling Low
Dampers modulate to maintain 55° supply air
Y2 Demand -
Compressors Off
Blower Cooling High
Dampers Modulate to maintain 55° supply air
Note - If dampers are at maximum open for three minutes,
compressor 1 is energized and blower stays on cooling
high. Economizer stays at maximum position after com
pressors are energized.
Y3 Demand -
Compressors 1 and 2 On
Blower Cooling High
Dampers Maximum Open
2-No Economizer or Outdoor Air Not Suitable
Y1 Demand -
Compressor 1 On Part Load
Blower Cooling Low
Y2 Demand -
Compressor 1 On Part Load Compressor 2 On.
Blower Cooling Medium
Y3 Demand -
Compressors 1 and 2 On
Blower Cooling High
