10-Unit Controller A55
-
to the Unit Controller guide provided with the unit. Ther-
11-Terminal Block TB13
TB13 terminal block distributes line voltage power to the
line voltage items in the unit.
12-Wireless Antenna
Wireless antenna is located above the return air com-
shows cable routing. Please follow the CORE Controller
setup guide included in the unit.
Antenna
Smoke Detector
Antenna Location
Return Air Section
FIGURE 4
Cable Routing
WIRELESS CONTROL
()BOARD W4
ANTENNA CABLE
ROUTING
FIGURE 5
To Next Page
